Se trata del best-seller de todos los monitores Focal Professional y al mismo tiempo la herramienta de trabajo más versátil de toda la serie SM6, tanto para grabación, mezcla y masterización.
Su precisión de la imagen sonora, definición en agudos, así como la neutralidad en el rango de medias frecuencias son los pilares básicos de su reputación. La excelente articulación de los registros graves y medios, incluso a niveles bastante altos, hacen de él una referencia inevitable para aquellos ingenieros que buscan una absoluta transparencia.
El diseño del Twin6 Be permite un alto SPL, ofreciendo al mismo tiempo un balance tonal ciertamente estable. Uno de sus 2 woofers de 6.5 pulgadas trabaja en un espectro amplio (rango de medios – graves) mientras que el otro reproduce de 40 a 150Hz, creando un componente en graves que preserva toda la dinámica de la señal, sin ningún tipo de efecto de enmascaramiento en frecuencias medias, y por ende, conservando toda su neutralidad y transparencia. Cuenta además con una serie de controles adicionales en su parte trasera para poder afinar su respuesta en graves con respecto a su monitor-pareja. Con el fin de responder a los requerimientos de espacio de cualquier estudio, el Twin6 Be se puede instalar tanto vertical como horizontalmente.
PREMIOS
• Pure Beryllium inverted dome tweeter The inverted dome tweeter is a hallmark of Focal. As a result of more than twenty years of development into a tweeter that could produce a high output, but without requiring high energy input and without increasing directivity. The introduction of the pure Beryllium dome, capable of covering 5 full octaves from 1,000 to 40,000Hz constitutes a new decisive advance regarding new audio formats. This tweeter capacity to reproduce high frequencies with unmatched speed and transparency. At first the pure Beryllium tweeter was only available on the very high-end digital speakers of the Focal Professional lines (SM8 & SM11), but is now featured on the new SM6 series, allowing an unprecedented price/performance ratio.
• The “W” cone Focal has been developing the technologies of composite sandwich cones for more than 15 years. The "W" process (Glass/Foam/Glass), used on the SM11, SM8 and SM6 lines, provides a true optimiza a true optimization of the frequency response by fine tuning of mass, rigidity and damping parameters. The balance between these 3 fundamental and often contradictory parameters is at the base of the outstanding sound neutrality of our speakers.
• A custom designed amplification stage Designing an amp to be integrated inside a speaker requires a very different set of rules than for a traditional amp. Speaker size and cooling concerns are often in contradiction with the high quality and high power requirements of a sonically transparent speaker. Our engineers used the BASH® technology to develop the bass/medium amplification circuit for the SM6 professional line of speakers. This was the only way to exploit the best of class AB style circuits (for exceptional quality) with a class D type yield, which is crucial when housing a 150W RMS circuit in such a small space (300W RMS for the Twin 6 and 350W RMS for the Sub6). A pure class AB circuit is sufficient to power the -less energy demanding- high frequency tweeter, allowing for an extremely wide bandwidth and exceptional accuracy
ideal for use in small professional studios. The MDF cabinet houses a pair of 6.5" "W" composite sandwich midwoofers, one of which handles bass while the other handles mid-bass frequencies to preserve signal dynamics without masking midrange. A rear-panel switch lets you choose which speaker handles which frequencies. A beryllium inverted dome tweeter provides crisp, clear treble. Each driver is powered by its own amplifier for a total of 400W of power.
The rear panel offers a standard XLR input connector, which allows you to connect to virtually any professional sound system. It also has an input sensitivity control and level controls for both the woofer and the tweeter, allowing you to adjust them separately to create the best sonic results for your environment. The monitor is magnetically shielded for safe use near video monitors and other electronic equipment, and it can be positioned horizontally or vertically for flexible placement.
- Rigid and durable MDF construction
- Pair of 6.5" "W" composite sandwich midwoofers, with one handling bass and the other handling mid-bass to preserve signal dynamics without masking midrange for neutral, transparent sound reproduction
- Dual drivers provide high SPL capability with stable tonal balance
- Rear-panel switch lets you choose which speaker is handling which frequency band
- Beryllium inverted dome tweeter provides crisp, clear treble
- Front laminar bass ports help to extend bass response
- Each driver is powered by its own amplifier for a total of 400W of power for a strong, distortion-free performance
- Standard XLR input connector allows you to connect to virtually any professional sound system
- Input sensitivity control and independent level controls for both the woofer and the tweeter
- Magnetically shielded for safe use near video monitors and other electronic equipment
- Can be positioned horizontally or vertically for flexible placement
-
Technical Specs.:
- Active, 3 way, professional nearfield/midfield speaker
- Perfect for use in music production, post-production or broadcast applications
- Frequency response: 40Hz-40kHz
- Maximum SPL: 115 dB SPL (peak@1m)
- Input - Type/impedance: Electronically balanced / 10 kOhms. Connector: XLR. Sensitivity: Adjustable, +4dBu ou -10dBV
- LF amplifier stage: 150W rms, BASH technology
- LF/MF amplifier stage: 150W rms, BASH technology
- HF amplifier stage: 100W rms, class AB
- User controls: Input level switch, LF and HF contours (potentiometers), Power ON/OFF switch, mains voltage selector
- Indicator (LED's): Power on LED
- Power supply - Mains voltage, Connection 230V (1.6A fuse rating) or 115V (3.15A fuse rating), IEC inlet and detachable power cord
- Transducers: 2 x Woofer "W" composite sandwich cone, Focal 6W4370B 6.5 inch drive unit. High frequency Focal TB871 Beryllium inverted dome tweeter. Shielding Integral through cancellation magnets or by magnet design
- Cabinet Construction: 19mm MDF panels internally braced
- Finish: Real red veneer sides - Black on body
- Dimensions (HxWxD): 250 x 500 x 340mm (9.8 x 19.7 x 13.4 )
- Weight: 14kg (30.8lb)
